The EM 100 G3 stationary receiver
5
The devices are available in the same UHF frequency ranges and are
equipped with the same frequency bank system with factory-preset
frequencies. An advantage of the factory-preset frequencies is that
• a transmission system is ready for immediate use after switch-on,
• several transmission systems can be operated simultaneously on the
preset frequencies without causing intermodulation interference.
The frequency bank system
The receiver is available in 6 UHF frequency ranges with 1,680 frequencies
per frequency range:
Each frequency range (A–E, G) offers 21 frequency banks with up to
12 channels each:
Range Range Range Range Range Range
516 – 558 566 – 608 626 – 668 734 – 776 780 – 822 823 – 865
Frequency bank 1... 20
Frequency bank U
Channel 12 – frequency preset
Channel 1 – frequency preset
Channel 2 – frequency preset
Channel 12 – freely selectable frequency
Channel 1 – freely selectable frequency
Channel 2 – freely selectable frequency
