SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 10007
Mar 13/13
23-41-48
FIG. ITEM PART NUMBER AIRLINE
PART NO.
NOMENCLATURE EFF
CODE
UNITS
PER
ASSY
-001 502397 HEADSET HMEC 26, WITHOUT CABLE RF
-001A 502403 HEADSET HMEC 26-KP A RF
-001B 502402 HEADSET HMEC 26-CP B RF
-001C 502405 HEADSET HMEC 26-V-CP C RF
-001D 502406 HEADSET HMEC 26-V-KP D RF
-001E 502401 HEADSET HMEC 26-BV-K E RF
-001F 502400 HEADSET HMEC 26-BV-CP F RF
-001G 502399 HEADSET HMEC 26-B-K G RF
-001H 502398 HEADSET HMEC 26-B-CP H RF
010 552768 . HEADBAND WITH HEADBAND PADDINGS
(SEE FIG. 18 FOR DET.)
2
020 531421 . LABEL FOR THE HEADSET 1
030 550222 . CLIP FOR THE CAP, NOT MICROPHONE SIDE,
"SENNHEISER HMEC 26" LABELED
1
040 600754 . CAP NOT MICROPHONE SIDE
(LABEL IS NEEDED)
1
050 538256 . ACOUSTIC UNIT, ACTIVE
NOT MICROPHONE SIDE
THE ACOUSTIC UNIT HAS BEEN REDESIGNED.
UP TO HEADSETS SERIAL NUMBER
00200100 ALWAYS REPLACE THE LEFT AND
THE RIGHT ACOUSTIC UNIT AND THE LEFT
AND RIGHT EARPAD (REF FIG. ITEM 100)
FROM HEADSETS SERIAL NUMBER
00200100 REPLACE THE DEFECTIVE
ACOUSTIC UNIT ONLY !
1
060 538257 . ACOUSTIC UNIT, ACTIVE
MICROPHONE SIDE
THE ACOUSTIC UNIT HAS BEEN REDESIGNED.
UP TO HEADSETS SERIAL NUMBER
00200100 ALWAYS REPLACE THE LEFT AND
THE RIGHT ACOUSTIC UNIT AND THE LEFT
AND RIGHT EARPAD (REF FIG. ITEM 100)
FROM HEADSETS SERIAL NUMBER
00200100 REPLACE THE DEFECTIVE
ACOUSTIC UNIT ONLY !
1
- ITEM NOT ILLUSTRATED
Oct 30/08
