SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 10008
Mar 13/13
23-41-48
-070 540366 . CAP WITH MICROPHONE ARM SUPPORT,
CABLE AND CLIP, MICROPHONE SIDE
(FROM SERIAL NO. 00200100)
1
080 550245 . MICROPHONE ARM, BKE 46-80
(FROM SERIAL NO. 00200100)
1
-080 529758 . MICROPHONE ARM STANDARD
. COMPLETE 80MV/PA
(UP TO SERIAL NO. 00200100)
1
090 522636 . SCREWS FOR THE RESONATOR 4
100 538258 . EARPADS, STANDARD PAIR 2
-100A 538259 . EARPADS, STANDARD, 100 PAIR 2
110 . CABLE 1
-110A 500842 . CABLE -KP (SEE FIG. 5 FOR DET.) A 1
-110B 500855 . CABLE -NP (SEE FIG. 6 FOR DET.) 1
-110C 500852 . CABLE -CP (SEE FIG. 7 FOR DET.) B 1
-110D 500853 . CABLE -V-RP (SEE FIG. 8 FOR DET.) 1
-110E 500846 . CABLE -V-CP (SEE FIG. 9 FOR DET.) C 1
-110F 500848 . CABLE -V-KP (SEE FIG. 10 FOR DET.) D 1
-110G 500839 . CABLE -BV-K (SEE FIG. 12 FOR DET.) E 1
-110H 500838 . CABLE -BV-CP (SEE FIG. 13 FOR DET.) F 1
-110I 502183 . CABLE -B-K (SEE FIG. 14 FOR DET.) G 1
-110J 504047 . CABLE -B-KP (SEE FIG. 16 FOR DET.) 1
-110K 500837 . CABLE -B-CP (SEE FIG. 15 FOR DET.) H 1
-110L 504030 . CABLE -BV-KP (SEE FIG. 12 FOR DET.) 1
-110M 502437 . CABLE -V-KX (SEE FIG. 11 FOR DET.) 1
ZZ120 515629 . HEADBAND PADDING, 1 PAIR 2
ZZ130 525211 . CABLE CLIP, HZC08, IN BULK, TBD TBD
ZZ130A 525787 . CABLE CLIP, HZC08, PACKAGED, 1 PCS 1
ZZ130B 044749 . CABLE CLIP, MZQ2002, IN BULK, TBD TBD
ZZ140 514127 . WINDSCREEN, IN BULK, TBD TBD
ZZ140A 515297 . WINDSCREEN, PACKAGED, 1 PCS 1
ZZ140A 502595 . HYGIENIC PADS HZH26 WHITE, 100 PAIR 2
ZZ140A 504062 . HYGIENIC PADS HZH26 BLACK, 100 PAIR 2
ZZ150 077408 . BAG 180X200X85 1
ZZ160 502595 . HYGIENIC PADS HZH26 WHITE, 100 PAIR 2
ZZ170 504062 . HYGIENIC PADS HZH26 BLACK, 100 PAIR 2
FIG. ITEM PART NUMBER AIRLINE
PART NO.
NOMENCLATURE EFF
CODE
UNITS
PER
ASSY
- ITEM NOT ILLUSTRATED
Feb 10/10
