SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 10009
Mar 13/13
23-41-48
FIG. ITEM PART NUMBER NOMENCLATURE EFF
CODE
UNITS
PER
ASSY
-001 540366 CAP WITH MICROPHONE ARM SUPPORT
MICROPHONE SIDE
RF
010 550221 CLIP FOR CAP, MICROPHONE SIDE 1
020 545287 SCREW 2X6 1
- ITEM NOT ILLUSTRATED
010
020
up
down
Figure 2
HMEC 26 headphone cap - microphone cap side
Oct 30/08
