SENS MicroGenius S2/S4 Technical Manual
38
from 6V to 98% of Float, must be at least 2%
less than Float setting
End Discharge
Adjust setpoint to trigger Battery End-of-
Discharge alarm, must be less than Low DC
setting
Low DC Voltage
Adjust setpoint to trigger Low DC voltage
alarm, must be greater than End Discharge
setting and less than Battery Discharging
setting
Batt Discharging
Adjust setpoint to trigger Battery Discharging
alarm, must be between Low DC setting and
98% of Float setting or Eco-Float setting
when HELIX is active
High DC Voltage
Adjust setpoint to trigger High DC voltage
alarm from 8 to 35V, must be greater than
Boost by 2% of Float setting, must be less
than 40% higher than Boost setting
Overvolt Fault
Adjust setpoint to trigger Over Voltage
Shutdown alarm from 8 to 35V, must be
greater than High DC setting
Low Current
Adjust setpoint to trigger Low Current alarm
from 0% to 50% of nominal current
Battery Set-up
Select DC Output (multiple output
models only)
Select output to adjust specific settings
Battery Select (type)
Select type of battery to be charged -
flooded lead-acid, AGM, nickel-cadmium
VRLA, power supply or ultracapacitor.
Battery Select (cells)
Adjust number of series cells in battery string
Batt Commission (voltage)
Adjust battery commissioning output voltage
from float voltage to 34V, must be greater
than or equal to Float voltage
Batt Commission (current)
Adjust battery commissioning output current
from 5% to 100% of nominal current rating
Batt Commission (duration)
Adjust battery commissioning hours from 1
to 120 hours
Batt Commission (enable)
Start or stop commissioning cycle. Charger
will deliver commissioning voltage and
current until commissioning hours expire.
Restore Factory Default Settings
Restore settings to factory configuration
Other Settings
Relay Assignment
Selection alarm relay assignments based on
application (see Tables 7-9)
Audio Alarm Mode
Mute or enable audible alarm indication
Keypad Click
Mute or enable audible beep upon keypad
button press
Number of Chargers
Enable or disable whether alarm is indicated
or not. Alarm active when the number of
charger modules active on SENSbus is less
than the minimum charger count. Disabled
by default, meaning no alarm. See Error
Code 301 for further details.
DC Output #A
Enable or disable output A for multiple
output models
DC Output #B
Enable or disable output B for multiple
output models
DC Output #C
Enable or disable output C for multiple
