16
Section 2 Model 7000 Series Turbine Flowmeter
Table2.5—PressureRatings(Bar)
Flange
Class
Type316SST7000SeriesTurbineMeterswithASMEB16.5Flanges
-29°C 38°C 50°C 100°C 150°C 200°C 250°C 300°C 325°C 350°C
CL 150 19.0 19.0 18.4 16.2 14.8 13.7 12.1 10.2 9.3 8.4
CL 300 49.6 49.6 48.1 42.8 38.5 35.7 33.4 31.6 30.9 30.3
CL 400 66.2 66.2 64.2 56.3 51.3 47.6 44.5 42.2 41.2 40.4
CL 600 99.3 99.3 96.2 84.4 77.0 71.3 66.8 63.2 61.8 60.7
CL 900 148.9 148.9 144.3 126.6 115.5 107.0 100.1 94.9 92.7 91.0
CL 1500 248.2 248.2 240.6 211.0 192.5 178.3 166.9 158.1 154.4 151.6
CL 2500 413.7 413.7 400.9 351.6 320.8 297.2 278.1 263.5 257.4 252.7
Size
Type316SST7000SeriesTurbineMeterswithNPT/BSPThreads
-29°C 38°C 93°C 149°C 204°C 260°C 316°C 343°C 371°C 399°C
1" * 303.4 303.4 261.4 235.6 216.2 201.7 190.4 187.2 182.4 180.7
1-1/4" 275.8 275.8 237.7 214.1 196.6 183.4 173.1 170.2 165.7 164.3
1-1/2" 220.6 220.6 190.1 171.3 157.3 146.7 138.5 136.1 132.6 131.4
2" 182.7 182.7 157.5 141.9 130.2 121.5 114.7 112.7 109.8 108.9
* 1-in. owmeters are not CE marked. The basis for PED conformance is Sound Engineering Prac-
tice (SEP).
