9
Scanner
®
2000 microEFM for Foundation™ Fieldbus Section 1
LCD / keypad
3/4 in. to 1 in. adapter
Union (connects directly
to the turbine meter)
LCD / keypad
Mount for pole-mount hardware
Ground screw
Conduit plug
Enclosure lid
(remove to access keypad)
Figure 1.2—Scanner 2000 microEFM with turbine meter adapter
Lithium battery pack
(double D cell), secured
by a velcro strap
Main circuit board
Battery connector
Fieldbus module
(attached to interface board)
Figure 1.3— Scanner 2000 microEFM, internal view
