METIS M311 / M322 / H311 / H322 (17-pin)
Communication via Serial Interface / Interface Commands
55
Set time (6-digit ASCII)
HH = hour, MM = minute, SS = second
Set time (6-digit ASCII)
HH = hour, MM = minute, SS = second
Show / hide temperature
X=0, 1; 0=Hide temperature; 1=Show temperature
Write own user text
TT...TT= Text (max. 16 ASCII characters)
White balance / automatic white balance
XX=0x00...64 (= 0...100% of the window area, calculated centric to the image cen-
ter) or ff (= automatic white balance)
Color saturation
XX=0x00…ff (= Level 0-255)
Camera module (power) on/off
X=0, 1; 0=off; 1=on
Definition of the image
XX=0x00…ff (= Level 0-255)
Brightness (AEC)
XX=0x00…ff (= Level 0-255)
Color transmission system camera module
X=0, 1; 0=NTSC; 1=PAL
Image setting color / monochrome
X=0...1; 0=color picture; 1=monochrome image
Test image
X=0, 1; 0=Normal image; 1=Test image
In addition, for devices with built-in motorized focus
Measuring distance
XXXX in mm (is possibly rounded up or down in 10 mm resolution!)
Old commands: to standardize the command structure, some old commands with numeric parameters
are replaced with new ones with hexadecimal coded. The old commands still work, but should no longer
used in reprogramming:
ms (Read temperature value, 5-digit. dec.) mw
kt1 (Read temperature channel 1) mw1
kt2 (Read temperature channel 2) mw2
qt (Read 2-color temperature, 5-digit. dec.) mw0
ez (Response time, 1-digit. dec.) et
lz (Max. value, 1-digit. dec.) lm in combination with lt
em (Emissivity, 2-digit. dec.) eg1
en1 (Emissivity channel 1, 2-digit. dec.) eg1
en2 (Emissivity channel 2, 2-digit. dec.) eg2
ev (Emissivity slope, 4-digit. dec.) eg0
aw (Switch-off level, 2-digit. dec.) ax
gt (Device temperature, 2-digit. dec.) ts
