E. INFINITY “S” SURFACE MOUNT SYSTEM
1114F7
FRONT PANEL
SIDE VIEW
2 1/2"
3 1/4"
3/4"
Speaker
Postal
Lock
Enclosure
Lock
Small
LCD
Display
11 3/4"
16.0"
Keypad
Micro-
phone
123
456
9
87
0
#
This line drawing is intended for dimensional reference purposes only and is not intended to be an actual
drawing of the Infinity “S” system itself.
