C. INFINITY “M” SURFACE MOUNT SYSTEM (SHOWN WITH OPTIONAL CCTV)
1564F1
Camera
Keypad
Micro-
phone
Speaker
Postal
Lock
Enclosure
Lock
2 X 20
LCD
Display
11 3/4"
16.0"
3 1/2"
4 1/4"
3/4”
FRONT VIEW
SIDE VIEW
123
456
9
87
0
#
This line drawing is intended for dimensional reference purposes only and is not intended to be an actual
drawing of the Infinity “M” system itself. NOTE: Camera is optional.
