Page 4 of 19 Doc 6001564 Rev B
B. CABLING TO THE TELEPHONE INTER FACE BOARD
Cabling to the Telephone Interface Board Type of Wire Recommendations
From the telephone company jack 2 conductor, Shielded-Belden #9501
18 to 22 awg cable Unshielded-Belden #8740
C. CABLING BETWEEN UNITS WITH DUAL SHORT HAUL MODEMS
(Multi-Link Systems only) Type of Wire Recommendations
From “LINE 2” on the first unit and 2 conductor, 16 to 24 awg Shielded-Belden #9501
“LINE 1” on the second unit (5000 ft. max.) twisted pair cable Unshielded-Belden #8740
D. CABLING BETWEEN UNITS WITHOUT DUAL SHORT-HAUL MODEMS
(Multi-Link Systems only) Type of Wire Recommendations
From “TB3” on the first unit and 5 conductor, Shielded-Belden #9929
“TB2” on the second unit (50 ft. max.) 18 to 24 awg cable Unshielded-Belden #8445
E. CABLING FOR ADDITIONAL FEATURES
On an Infinity System Type of Wire Recommendations
From a computer terminal 3 conductor Use shielded cable only
to the Main Processor Board (50 ft. max.) 16 to 24 awg cable Shielded-Belden #9925
From a printer 3 conductor Use shielded cable only
to the Main Processor Board (50 ft. max.) 16 to 24 awg cable Shielded-Belden #9925
From a Stand-Alone Modem 3 conductor Use shielded cable only
to the Main Processor Board (50 ft. max.) 18 to 24 awg cable Shielded-Belden #9925
From a Remote Keypad 7 conductor Use shielded cable only
to the Main Processor Board (500 ft. max.) 20 to 24 awg cable Shielded-Belden #9932
From a Wiegand, Barium Ferrite, Proximity,
or Clikcard card reader to the 5 conductor Use shielded cable only
Main Processor Board (500 ft. max.) 24 awg cable Shielded-Belden #9929
On a Multi-Link System Type of Wire Recommendations
Between a Computer Terminal 3 conductor Use shielded cable only
and the first unit of the system (50 ft. max.) 18 to 24 awg cable Shielded-Belden #9925
Between A Computer Terminal 2 conductor, Use
unshielded
cable only
and a Stand-Alone Short Haul Modem (50 ft. max.) 16 to 24 awg, Unshielded-Belden #8740
twisted pair cable
Between a Printer and the 3 conductor Use shielded cable only
first (or last) unit of the system (50 ft. max.) 18 to 24 awg cable Shielded-Belden #9925
Between a Printer and a 2 conductor, Use
unshielded
cable only
Stand-Alone Short-Haul Modem (50 ft. max.) 16 to 24 awg, Unshielded-Belden #8740
twisted pair cable
Between a Printer and 2 conductor Use shielded cable only
the AUX port of a terminal (50 ft. max.) 18 to 24 awg cable Shielded-Belden #9501
