Sentex Infinity - Power Supply Board with Camera (1110076)

Rev B Doc 6001564 Page 19 of 19
D. 1110076 POWER SUPPLY BOARD WITH BOARD MOUNT CAMERA
IMPORTANT NOTE:
Do not use the same power supply for this board as for the telephone entry system. The power inputs
must be isolated.
