Specifications
700-0098 R006 A–1
APPENDIX A
Specifications
This appendix provides the product specifications for the Trooper TL4 and TL2
Mobile DVR System.
A.3. Trooper TL
Note: Specifications are subject to change without notice.
Video Input/Output 75 Ohm NTSC video
Video Resolution 720 × 480, 720 × 240, or 360 × 240 pixels
Video Compression H.264
Media Storage Hard drive
DVR Drive Removal Hot swappable, locking key-secured
Audio Input Level –8 dBm
Audio Output Level –6 dBm, 10 kOhm
Operating Temperature –22°F to 122° F (–30°C to 50°C)
Storage Temperature –40°F to 158°F (–40°C to 70°C)
Operating Humidity 0 to 95% relative humidity, non-condensing
Operating Voltage 8 to 32 VDC
Transient Protection 600 W per signal input
Temperature Protection Advanced Smart-Temp
Control Input Connector 1x2-pin Microfit
Power Output Connector 1x2-pin Microfit
Camera Input Connectors 2x3-pin Microfit
Ethernet RJ-45
Audio Input Connectors 2x2-pin Microfit
Alarm Input Connector 1x2-pin Microfit
Video Output Connector BNC
Adapter Harness 12-pin Molex
DVR Drive Dimensions (H × W × D) 0.83 × 3 ×5.1" (21 × 76 × 130 mm)
DVR Dimensions (H × W × D) 2 × 7 × 6.5" (51 × 178 × 165 mm)
DVR Weight 5.3 lb (2.4 kg) with front cover, cable cover
Fuses: Power Circuit and Ignition Circuit 5 A and 1 A
