Serpent F110 SF4 - Page 16

16
STEp 21 STEp 22
1/4x3/8
Flanged
8x12x3.5
M3X8 Special
Pinion is not included in the
kit. Assemble the proper
pinion for your set-up.
The M3x8 special head screw is normally enough to hold the
wheelhub. However, if you deem it necessary, you can insert a
M3x4 set screw on the other side.
M3x10
M3x10
1/4x3/8 Flanged
8x12x3.5
