15
18.2
STEp 18
18.3
6x10x3
Flanged
6x10x3
Flanged
6X10X3 Flanged
M3x10
3
2
2
4
1
1
5x7
M3x10
M3x6
M3x10
After tightening the M3x10 screws check that the
brake pads slide easy over the bushings.
5x7
18.1
M3x6
