Serpent VIPER 990 - Page 22

22
bag 8
M4X12
M4x12
2mm
1mm
1
2
M3x8
M4x12
STEp 27
M3x6
M3x8
27.1 27.2
M3x6
2
FRONTANTIROLL
BARRODLENGTH
28 mm
Serpent 990 allows to move front bottom arms 3 mm in (NARROW) and out (WIDE). To maintain the same
shock angle, use the suspension bracket and shock bracket as shown here.
FRONTLOWERSUSPENSIONANDSHOCKBRACKETS
WIDENARROW
