32
44.1
STEp 44 STEp 45
M3x10
Use these spacers depending
on the type of battery.
44.2
Use tape to mount the battery
to the plastic support.
M3x6
M3x6
M3x6
M3x6
M3x8
M3x8
M3x10
M3x6
M3x8
