SCORPIO LIGHT SERIES 10’/17’/23’L - DOCUMENTATION - Weights of the cranes
Version 1.04 May 26, 2022
86
TRANSPORT WEIGHTS:
*The size and the weight of these packages are based on standard packages. It may change based
on the customer order.
Package
Format
Size
Weight
S10’ Arm
Flight case
248x80x45 cm
204kg
S10’ Dolly & Column
Plywood crate
139x94x76 cm
155kg
S10’ Counterweights & CW dolly
Pallet
120x80x65 cm
400kg
Package
Format
Size
Weight
S17’ Arm
Plywood crate
299x66x55 cm
240kg
S17’ Fulcrum & accessories
Plywood crate
94x55x84 cm
109kg
S17’ Dolly & Column
Plywood crate
139x94x76 cm
155kg
S17’ Counterweights & CW dolly
Pallet
120x80x60 cm
420kg
Package
Format
Size
Weight
S23’L Arm
Plywood crate
350x55x75 cm
294kg
S23’L Fulcrum & accessories
Plywood crate
94x55x84 cm
116kg
S23’L Dolly & Column
Plywood crate
139x94x76 cm
155kg
S23’L Counterweights & CW
dolly
Pallet
120x80x60 cm
450kg
