Supervisor Setup • Super II 35
SETUPS
MORE
SUPER
SETUP
abc reset
tare
menu remote
TRANSAC
SETUP
MORE
Select TL fields using the numeric keys:
1. PART ID 4. OPRTR
2. LOT # 5. COUNT
3. DESC. 6. TIME/DATE
TURN TL CHOOSE PRINT CLEAR GO BACK
ON/OFF FIELD 4 TRANSFR TL
Soft Key:
TRANSAC SETUP
The controller has memory for an extensive database which has a number of configurations. The
database can contain two different types of records: database records and transactions. Database
records contain stocking information and can be recalled using the PART ID (IDØ). Transactions are
stored and accessed sequentially and each contains information about a single event or action
performed on a single part. The database can hold up to 750 records in any combination of database
records and/or transactions. See DATBASE SETUP for details about setting and using database
records.
Transactions can contain up to six fields of information:
TL RECORD:
PART ID (IDØ): (up to 23 characters)
LOT # (ID3): (up to 16 characters)
DESC (ID4): (up to 16 characters)
User Selectable ID: (up to 16 characters)
Count:
Time/Date:
Any of the fields may be enabled or disabled. A disabled field will not be stored, displayed or printed.
To access the TRANSAC SETUP menu, either follow the menu tree or press the keys in the order below:
The following menu appears and the soft keys change to:
The Transaction Log will make a record of any combination of the above fields. To choose which fields
will be recorded each time the SAVE key in the User menu is pressed, simply select the field using the
numeric keypad. Selected fields will appear with the light background whereas fields not chosen will
be in reverse video with a dark background.
