Supervisor Setup • Super II 36
Select TL fields using the numeric keys:
1. PART ID 4. OPRTR
2. LOT # 5. COUNT
3. DESC. 6. TIME/DATE
TURN TL CHOOSE PRINT CLEAR GO BACK
ON FIELD 4 TRANSFR TL
Select TL fields using the numeric keys:
1. PART ID 4. OPRTR
2. LOT # 5. COUNT
3. DESC. 6. TIME/DATE
TURN TL CHOOSE PRINT CLEAR GO BACK
ON/OFF FIELD 4 TRANSFR TL
Select TL fields using the numeric keys:
1. PART ID 4. OPRTR
2. LOT # 5. COUNT
3. DESC. 6. TIME/DATE
TURN TL CHOOSE PRINT CLEAR GO BACK
ON/OFF FIELD 4 TRANSFR TL
Select the TURN TL ON/OFF soft key to activiate the Transaction Log. When the Transaction Log is off,
access to the saving, viewing, and printing screens are disabled but the format is retained.
Selection #4 is a user definable ID field. The default choice is the OPRTR (ID1) field, but can be changed to
any of the available ID registers. To change Selection #4, press the CHOOSE /FIELD 4 soft key.
The ID selection menu will then appear:
To activate the desired ID field for the Transaction Log, simply use the numeric keypad and enter the
number for that ID field. The selected ID will appear with the light background whereas the other IDs
will appear in reverse video with a dark background.
Press PRINT TRANSFR to send the Transactions stored in the Transaction Log to an RS232 port.
Select the extra Tl field:
GO BACK
IDØ: PART ID ID4: DESC ID8:
ID1: OPRTR ID5: VENDOR ID9:
ID2: ORDER # ID6: REV #
ID3: LOT # ID7:
