9
Satellites - External devices
Satellites (Green LED)
Status
Action
Turned Off
Not receiving Satellites
Flashing “n”
constant
flashes
Receiving “n” Satellites
Constant rapid
flashing
Error
External devices (Red LED)
Status
Action
Turned Off
Device not linked
Constant
flashing
(1 per
second)
Total Station linked via USB
Constant
flashing
(2 per
second)
Total Station linked via bluetooth
Constant
flashing
(3 per
second)
Station connected via cable and
bluetooth
USB - RS232
USB (Green LED)
Status
Action
Turned Off
Device Disconnected
Constant
flashing
(2 per
second)
Device connected via USB in LEMO 2
RS232 (Red LED)
Status
Action
Turned Off
Device disconnected
Constant
flashing
(1 per
second)
Device connected via RS232 in LEMO1
Constant
flashing
(2 per
second)
Device connected via RS232 in LEMO2
