Settop M1-15 - Back View

10
Constant
flashing
(3 per
second)
Device connected via RS232 in LEMO1
and LEMO 2
Constant
flashing
(1 Hz)
Service mode
Back View
Phone
GSM Antenna connector
COM1
Lemo connector for RS232/ power in
COM2
Lemo connector for USB / power in/out
Phone
GSM Antenna connector
Satellites
GPS Antenna connector
