SEW-Eurodrive DFE33B User Manual

6
Ethernet Industrial Protocol (EtherNet/IP)
CIP object directory
Manual – Fieldbus Interface DFE33B EtherNet/IP and Modbus/TCP
55
6.3 CIP object directory
In the Common Industrial Protocol, all unit data can be accessed via objects. The
objects listed in the following table are integrated in the DFE33B option.
The meaning of the objects and a description of how to access them is given in the
following section.
Identity object • The identity object contains general information on the EtherNet/IP device.
• Class code: 01
hex
Class
Instance 1
Class [hex] Name
01 Identity Object
02 Message Router Object
04 Assembly Object
06 Connection Manager Object
07 Register Object
0F Parameter Object
64 Vardata Object
F5 TCP/IP Interface Object
F6 EtherNet Link Object
Attribute Access Name Data
type
Default value
[hex]
Description
1 Get Revision UINT 0001 Revision 1
2 Get Max Instance UINT 0001 Maximum instance
Attribute Access Name Data type Default value [hex] Description
1 Get Vendor ID UINT 013B SEW-EURODRIVE GmbH & Co KG
2 Get Device Type UINT 0065 Manufacturer-specific type
3 Get Product Code
1)
UINT 0003
0004
Product no. 3: DFE33B for MOVIDRIVE
®
B
Product no. 4: DFE33B as gateway
4 Get Revision STRUCT of Revision of the identity object, depends on
firmware version
Major Revision USINT
Minor Revision USINT
5 Get Status WORD Æ Table "Coding of attribute 5 status"
6 Get Serial Number UDINT Unique serial number
7 Get Product Name
1)
SHORT_STRING SEW-MOVIDRIVE-DFE33B
SEW-GATEWAY-DFE33B
Product name
1) The values in the identity object depend on whether the DFE33B option is used in MOVIDRIVE
®
B or as gateway.
