Technical data and dimension sheets
Technical data
Operating Instructions – MOVIMOT
®
flexible
374
11.3.4 Current carrying capacity of terminals
Current carrying capacity of terminals
Line terminals X1 24A (max. loop-through current)
Control terminals X9 10A (max. loop-through current)
11.3.5 DC24V supply
Input for the independent backup voltage supply of the electronics
DC24V input 24V_IN U
IN
= DC24V -10%/+20% according to EN61131-2
Current consumption:
I
E
≤500mA, typically 250mA for electronics
• Plus up to 100mA for the safety option
• Plus up to 100mA for 2 digital outputs (50mA each)
• Plus up to 500mA, for sensor supply
0V24_IN
11.3.6 DC24V auxiliary output
Internal voltage supply, only for non-safety-related enable signal via STO input
DC24V auxiliary out-
put
X9
24V_OUT U
OUT
= DC24V -10%/+20% according to EN61131-2
External-voltage-proof and short-circuit proof
Permitted output current: I
OUT
≤ 50mA
0V24_OUT
11.3.7 Digital inputs
Digital inputs
Number of inputs 4 (+ 2)
Input type PLC-compatible according to EN61131-2 (digital inputs type3)
DI01 – DI04: R
i
≈4.5kΩ, sampling cycle ≤2ms
DIO01 – DIO02: R
i
≈4.0kΩ, sampling cycle ≤2ms
Signal level
DC +11 to +30 V = "1" = Contact closed
DC -3 to +5 V = "0" = Contact open
Sensor/actuator supply DC24V to EN61131-2,
External-voltage-proof and short-circuit proof
Maximum line length 30m
Permitted total current for
internal supply
250mA (total of all connected sensors/actuators, maximum individual load:
250mA)
Permitted total current for
external supply
500mA (total of all connected sensors/actuators, maximum individual load:
500mA)
