4
Mechanical installation
Tightening torques
Operating Instructions – MOVIMOT
®
flexible
41
4.8.2 Cable glands
Tightening torques
Tighten the EMC cable glands optionally supplied by SEW‑EURODRIVE to the fol-
lowing torques:
Screw fitting Part
number
Content Size Outer
cable di-
ameter
Tighten-
ing
torque
EMC cable glands
(nickel-plated brass)
18204783 10 pcs M16 × 1.5 5 to 9mm 4.0Nm
18204805 10 pcs M25 × 1.5 11 to
16mm
7.0Nm
EMC cable glands
(stainless steel)
18216366 10 pcs M16 × 1.5 5 to 9mm 4.0Nm
18216382 10 pcs M25 × 1.5 11 to
16mm
7.0Nm
The cable retention in the cable gland must withstand the following removal force of
the cable from the cable gland:
• Cable with outer diameter >10mm: ≥ 160N
• Cable with outer diameter < 10mm: = 100N
29128668/EN – 12/2019
