5
Electrical installation
Bulk cables
Operating Instructions – MOVIMOT
®
flexible
67
Connection of bulk cables
The following table shows the conductor assignment of cables with the following part
numbers:
Part numbers
28118723, 28118707, 28118731, 28118715
Connection description
Bulk cable Description
Core color/
Core cross
section
Identific-
ation
Signal
Brown
2.5mm
2
4.0mm
2
L1 L1 Line connection, phase L1
Black
2.5mm
2
4.0mm
2
L2 L2 Line connection, phase L2
Grey
2.5mm
2
4.0mm
2
L3 L3 Line connection, phase L3
Green/yel-
low
2.5mm
2
4.0mm
2
– PE PE connection
Brown
2.5 mm
2
– +24V DC24V
Blue
2.5mm
2
– 0V24 0V24 reference potential
White
0.34 mm
2
– Res. Reserved
1)
Yellow
0.34 mm
2
– Res. Reserved
1)
Blue
0.34 mm
2
– Res. Reserved
1)
Orange
0.34 mm
2
– Res. Reserved
1)
1) Reserved wires must be isolated and fixed in the connection box.
29128668/EN – 12/2019
