5
Electrical installation
Assignment of the optional plug connectors
Operating Instructions – MOVIMOT
®
flexible
94
Connection of cables with open end
The following table shows the conductor assignment of cables with the following part
numbers:
Part numbers
18180094, 18127479, 18133967, 18153283, 18153291, 18127495, 18133983, 18153321, 18153348
Assembly
Open cable end Description Prefabricated plug
connectors
D
3
2
1
PE
C
B
A
5
4
6
Core color/
Core cross
section
Identi-
fication
Assembly Signal Contact
Black
1.5mm
2
2.5mm
2
1
Not pre-
fabricated
Line connection, phase L1 L1 A
Black
1.5mm
2
2.5mm
2
2
Not pre-
fabricated
Line connection, phase L2 L2 B
Black
1.5mm
2
2.5mm
2
3
Not pre-
fabricated
Line connection, phase L3 L3 C
Green/yel-
low
1.5mm
2
2.5mm
2
–
Not pre-
fabricated
PE connection PE PE
29128668/EN – 12/2019
