SI 480E DIN SIZE WEIGHING CONTROLER
External Input Selection 1 (IN1) – Input Terminal No.1
F14
●
0
ZERO
1
TARE
2
TARE RESET
3
TARE / TARE RESET
4
HOLD
5
HOLD RESET
6
HOLD/HOLD RESET
7
PRINT
8
PRINT the amount
External Input Selection 2 (IN2) – Input terminal No.2
F15
0
ZERO
1
TARE
2
TARE RESET
●
3
TARE / TARE RESET
4
HOLD
5
HOLD RESET
6
HOLD/HOLD RESET
7
PRINT
8
PRINT Grand total
Equipment No. setting – ID No.setting
F18
01
01~99
ID No. setting with No. key. (01~99 settable)
■ Communication Mode Setting
Parity Bit selection Mode
F30
●
0
DATA Bit (8 Bit)
STOP Bit (1 Bit)
Parity Bit (Non)
1
DATA Bit (8 Bit)
STOP Bit (1 Bit)
Parity Bit (Odd)
2
DATA Bit (8 Bit)
STOP Bit (1 Bit)
Parity Bit (Even)
3
DATA Bit (8 Bit)
STOP Bit (2 Bit)
Parity Bit (Non)
4
DATA Bit (8 Bit)
STOP Bit (2 Bit)
Parity Bit (Odd)
5
DATA Bit (8 Bit)
STOP Bit (2 Bit)
Parity Bit (Even)
6
DATA Bit (7 Bit)
STOP Bit (1 Bit)
Parity Bit (Odd)
7
DATA Bit (7 Bit)
STOP Bit (1 Bit)
Parity Bit (Even)
8
DATA Bit (7 Bit)
STOP Bit (2 Bit)
Parity Bit (Odd)
9
DATA Bit (7 Bit)
STOP Bit (2 Bit)
Parity Bit (Even)
