The MAC-200 has a miniature power input jack on the back panel.

Any voltage from 10 to 18.5 VDC is suitable for operation.

Average current draw will be approximately 230 milliamps. The

MAC-200 should be powered from the same power source used to

supply your transceiver to ensure that it is energized whenever the

transceiver is in operation.

3.2.2 RF Input from your transceiver

A standard SO-239 jack is for RF Input from your transceiver.

3.2.3 Chassis Ground

12 VDC

Chassis

Ground
