2 Technical Specifications
HF Frequency Range 1.8-60Mhz
Power Input 1.5-200 watts PEP
Number of Inputs 1 type SO239
Revolving Memory Bins 168
Number of Outputs 5 – 1 End Fed, 1 Balanced Feed, 3
Coaxial
Network Pi Configuration
Impedance Range
Longwire .2-5000 ohms
feedline 5-1000 ohms
Balanced Output 5-1000 ohms
VSWR Typically less than 2:1
DC Input Requirement +13.8 VDC (nominal)
DC Operating Range +10 to 18.5VDC
Input Current 230 milliamps average
Random Set Time Typically < 2 seconds
Recurrent Set Time Typically < 10 ms
Antenna Length (Long Wire) Minimum 9 ft – 7-30Mhz
Minimum 40 ft - 3-30Mhz
Minimum 100 ft – 1.8-30Mhz
Installation Desktop
Operating Temperature -35 to +70C
Size 6.5 X 3 X 8.5 inches
Weight 5 pounds
Case Construction Extruded Aluminum
Meters 1 SWR
1 Power with 20 & 200 watt scales
Cable Connections Standard Coaxial PLUS
Standard mini-plug for DC PLUS
Lugs for wire antennas and ground
