3.3 Antennas and the MAC-200
The MAC-200 can accommodate a wide variety of antennas
providing a convenient way to switch between them and to tune
them, all in the same box.
3.3.1 Optimum Coupling
The MAC-200 incorporates a coupler internally to provide for
tuning on a variety of antennas under direct control of the user.
This is a compromise location. The optimum location is the
antenna feed point where the impedance match keeps SWR on the
feed line to an absolute minimum.
