13
One Omega bracket is supplied with the device if it is to be flown above the
ground. Remove the floor stand/base and rig the P-2 to a support truss or struc-
ture using the supplied brackets and suitable clamps.
Fasten a safety cable (not shown) between the support
structure and the attachment point on the device. The
safety cable must be able to bear at least 10 times the
weight of the device.
The device can be tilted from 0° - 180°. To adjust the tilt angle, loosen the two tilt screws,
one of each side of the device, tilt the device to the angle required and
re-tighten the screws.
CAUTION: If the device has been operating, always allow it to cool for 15 minutes

before handling.
WARNING! Always secure an elevated P-2 with a safety cable as backup.
