SGM P-2 - DMX protocols; 15 Channel Mode (RAW) - Full RGBW control

26
DMX protocols
Configuring DMX is described in “Setting the DMX mode” on page 18.
15 Channel Mode (RAW) - Full RGBW control
Channel Name DMX value
DMX
percentage
Description Info
Default
DMX
value
Fader type
1 Shutter
07
0,0% 2,7% Closed 10 (3,9%) Snap
815
3,1% 5,9% Open 0 (0%) Fade
16 151
6,3% 59,2% Strobe Fast > Slow 0 (0%) Fade
152 175
59,6% 68,6% Pulse - Open Slow > Fast 0 (0%) Fade
176 199
69,0% 78,0% Pulse - Close Slow > Fast 0 (0%) Fade
200 244
78,4% 95,7% Strobe - Random Slow > Fast 0 (0%) Fade
245 255
96,1% 100.0% Open 0 (0%) Fade
2 Intensity 0 255
0,0% 100,0%
No light > 
Maximum light
0 (0%) Fade
