9
Overview
The P-2 is a DMX-controllable, low-profile, IP65-rated, rectangular, LED wash light. It has full RGBW color mixing, color tem-
perature control and incorporates 18 high-power 10W RGBW LEDs divided into 3 individually controllable segments for wide
ranging color and effect combinations. The P-2 offers a variation of beam angles with 15°, 21° or 43° interchangeable lenses.
The P-2 also features dimming, RGB color mixing, color temperature control, a (half-peak) spread angle of 110° and a lamp
life expectancy of 50,000 hours*.
This manual covers installation, use and maintenance of the P-2. All documentation is also available from the SGM web-site:
http://www.sgmlight.com
* At 70% of luminous output under the manufacturer’s test conditions.
P2 Manual_170x113,3.book Page 9 Wednesday, January 7, 2015 11:47 AM
