ASSEMBLY
PREPARATION FOR STARTING
1. Before running the compressor remove
the plug and connect the breather pipe to
the oil-hole.
2. Screw both the air filters in either side
before starting the compressor.
3. Set the compressor in a clean, dry and
ventilated area.
4. Keep voltage within ±4% of the rated
value.
5. Keep the oil level in the red circle of
the oil glass sight window. You can pur-
chase compressor oil from our website at:
www.sgs-engineering.com
Use a spanner to attach the
wheels to the compressor.
Use the washers and spring
washer in the positions
shown.
Insert the support foot into
the position shown.
Check all nuts and bolts.
Make sure all loosened
parts are tightened before
starting.
