PAGE 3
PAGE 2
SPECIFICATION
WARNING
Read and understand instructions before use.
Always wear eye/face and hand protection.
ITEM DATA
Model SC90B SC150B
Power 2200W / 3 HP
Voltage 230 V
Frequency 50 Hz
Delivery 14 CFM
Max Discharge Pressure 150 PSI / 10 BAR
Tank Capacity 90 L 150 L
Dimensions
990 x 440 x 880 mm 1400 x 475 x 890 mm
Oil / Oil Free Oil Lubricated
Wheel Mounted Yes
Air Outlets 2
Air Outlet Size 1/4”
Net Weight 69 kg 81 kg
Noise Information LWA 97 dB
Risk of electric shock. The compressor must be discon-
nected from the mains supply before maintenance or re-
moving any covers. Do not use in a damp environment.
Risk of accidental start-up. The compressor could start
automatically in the event of a power cut and subse-
quent reset. Do not carry the compressor while it is con-
nected to the power source, or when the tank is filled
with compressed air.
This compressor contains surfaces which may reach a
high temperature during operation. Never operate with
the motor housing removed.
Air and condensation water can burst from the compres-
sor when the drain plug is removed.
This compressor produces a high sound level during
operation. Ear protection should be worn.
WARNING
WWW.SGS-ENGINEERING.COM
