SGS SC90B - Quick Reference

PAGE 7
PAGE 6
QUICK REFERENCE
1. Guard
2. Capacitor / motor control box
3. Oil breather plug
4. Motor unit
5. Air delivery pipe
6. Air reciever
7. Feet
8. Oil sight glass
9. Drain valve
10. Air reciever pressure gauge
11. Regulated air outlet pressure gauge
12. Air outlet (regulated pressure)
13. Pressure regulator
14. On / off switch
15. Flywheel / fan
16. Pump unit
17. Air intake filter
QUICK REFERENCE
WWW.SGS-ENGINEERING.COM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
