IMPORTANT! Before starting the machine remove all the
travel plugs and attach the Air Filter and the Crank Case
Breather Plug.
SETTING UP THE COMPRESSOR
The compressor is
equipped with a safety
valve. If the pump were to
continue operating above
the maximum pressure,
the safety valve would
open and eject air from
the vessel. If the safety
valve discharges air, please turn off the compressor and contact the hel-
pline. The safety valve is located to the side of the pressure switch.
Filling the sump with oil
Pour approximately 0.5L of oil into the sump until the oil level reaches the
red spot in the centre of the sight glass (see image below). Once the oil
has reached the correct level re-insert the oil breather plug.
SETTING UP THE COMPRESSOR
WWW.SGS-ENGINEERING.COM
