ASSEMBLY
(Click)
1
(Click)
2
(Click)
(Click)
4
3
(Click)
(Click)
5
3 WAYS TO CHARGE THE LITHIUM-ION BATTERY
IN VACUUM
OUT OF VACUUM
IN CHARGING CRADLE
NOTE: only one charger is provided.
NOTE: When using the cradle, insert the charger plug into the port and rotate to lock into place.
The battery will not charge unless the charger is locked into place.
To remove the battery for charging, lift the handle
on top of the battery and pull up. The battery must
be charged before first use.
A complete charge takes approximately 3.5 hours.
IMPORTANT: When charging, connect the charger to
the port first, then plug the charger into wall outlet.
1. Insert wand into floor nozzle.
2. Insert handle into wand.
3. Align the bottom of pod onto the rails on the front of the neck of the floor nozzle.
Slide pod down the rails until it clicks into place.
4. Connect hose to back of pod, and attach hose clip onto wand.
5. Insert charged battery into pod with the handle toward the back until it clicks.
To ensure proper insertion, the handle on battery must be down.
IMPORTANT: For proper operation, ensure all connections are securely clicked into place.
4
3
