GETTING TO KNOW YOUR SHARK MATRIX™ 2-IN-1 ROBOT
Charging Dock
DOCK FRONT
FLUID RESERVOIR
DOCK LANDING MAT
(This side up)
DOCK BOTTOM
Charging Contacts
Fill Port and
Release Button
Pad Slot
Charger Cord Wrap
DOCK SETUP
2 ft.
1 ft.
1 ft.
• Select a permanent location with strong Wi-Fi for the Charging Dock, because every time you relocate it,
your robot will have to completely re-map your house.
• Place the dock with its back against a wall and attach the landing mat. Select a level surface on bare floor,
in a central area. Do not place dock against baseboards or heating elements.
• Remove any objects that are closer than 1 foot from either side of the dock, or closer than 2 feet from the
front of the dock.
• Plug in the dock.
INSTALLING THE SIDE BRUSH
Snap the included Side Brush onto the square peg
on the bottom of the robot.
NOTE: Side brush design may vary.
