SHARK TRAILER SERVICE MANUAL • 9.801-302.0 • Rev. 4/14
9
TRAILER
SERVICE MANUAL
TRS-2500 WITH SGP WASHER PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 8.917-561.0 Wlmt, Mount, Feed Pump 1
2 8.917-564.0 Cover, Mount, Feed Pump 1
3 8.706-510.0 Bumper, Rubber, 3/4"
w/Washer 4
4 8.725-945.0 Pump, 4.0 GPM, 12V, 10A 1
5 8.915-292.0 Reel, Hose, Bracket,
Mount Retainer 2
6 8.706-902.0 Nipple, 3/4"JIC x 1/2" Pipe 1
7 9.802-152.0 Swivel, 3/4" SAE FEM,
Push-on 4
8 8.706-984.0 Adapter, 1/2" FPT x 1/2"
MPT, Brass 1
9 9.802-132.0 Elbow, 3/4" JIC x 1/2" MPT,
90° 1
10 8.718-626.0 Bolt, 5/16"-18 x 1-1/4", NC
Carriage Z 8
11 8.718-980.0 Washer, 5/16", Flat,
SAE (780452) 8
12 9.802-776.0 Nut, 5/16", ESNA, NC 8
13 9.802-453.0 Switch, Curvette
RA901VB-B-1-V.Carling 1
14 9.803-551.0 Screw, 5/16" x 3/4"
Whiz Loc Flange 2
15 9.802-261.0 Hose, 3/4" Push-on, /ft 2
16 9.802-722.0 Bolt, 3/8" x 1-1/4", NC HH 8
17 9.802-807.0 Washer, 3/8", SAE,
Flat Zinc 16
18 9.802-779.0 Nut, 3/8", ENSA, NC 8
19 9.802-166.0 Coupler, 3/8" Female, Brass 1
20 8.711-708.0 Hose, 1/2" X 90" 2 Wire,
Pressure Loop 1
21 9.802-038.0 Nipple, 1/2" JIC x 1/2" MPT,
Steel 1
22 9.802-261.0 Hose, 3/4" Push-on, /ft 3
23 8.706-826.0 Elbow, 1/2" Street 1
24 8.706-797.0 Nipple, 1/2 Hex 1
25 8.707-212.0 Valve, 1/2" Brass, 3-way 1
26 9.802-146.0 Swivel, 1/2" MP x 3/4" GHF
w/Strainer 1
27 9.802-204.0 s Clamp, Wire/Tube, 0.750D 1
28 9.802-799.0 s Screw, #14 x 1", Tek,
Blk., Zinc 1
29 9.802-514.0 Strain Relief, Small 1
30 9.802-456.0 Light, Indicator, Green, 12V 1
s Not Shown
