SharkRack Enclosure Installation Guide
ID-00210-000 REV D, ECO2773 Page 10 of 46
Unpacking Instructions- Standard Packaging
Step Detail
Note: Unpacking of a cabinet requires at least two
people.
There must be at least 7 feet of clear area in front of the
loaded pallet to unload the cabinet.
1. Unwrap packaging material from around the cabinet
Figure 5
42U X 42in DP Shown
2. Remove the (4) bolts securing the front Floor
Mounting Bracket to the pallet and cabinet.
3. Repeat Step 2 for the rear Floor Mounting Bracket
Figure 6
42U X 42in DP Shown
Removal of Floor Mounting Bracket.
