SharkRack 37U - Installing and Removing Doors

SharkRack Enclosure Installation Guide
ID-00210-000 REV D, ECO2773 Page 15 of 46
Installing and Removing Doors
Step Detail
To remove doors:
1. Open the door.
2. Pull down on the spring-
loaded hinge pin
attached to the top of
the door.
3. Move top of door away
from enclosure and lift
the bottom of door up
from the cabinet and set
aside.
Figure 12
42U X 37DP Shown
#2
#3
