EN-3
ENGLISH
INDOOR UNIT
1
Inlet(Air)
2
Air Filter
3
Front panel cover
4
HorizontalAirowLouver
5
ON/OFFButtonandReceiverWindow
6
Motion Sensor (Forpremiummodelsonly)
7
VerticalAirowLouver
8
Outlet(Air)
9
OPERATIONLamp(Green/Blue )
10
TIMER Lamp (Orange )
1 1
WLAN Lamp (Green )(Forpremiummodelsonly)
9
10
11
9
10
Premium models
Deluxe models
1
2
3
4
5
6
7
8
Indoor unit apperance may be different from the image above.
※
PART NAMES
