Command table
How to read the command table
Command:
Direction:
Command field
W When the “Parameter” is set in the parameter field, the command functions as described under “Control/Response Contents”.
?” in the
R The returned value indicated under “Reply” can be obtained by setting “????” or “ parameter field.
Power control/Input mode selection
Picture menu
Function Command Direction Parameter Reply Control Response content Remarks
POWER CONTROL POWR
W
0 Switch to standby mode
• Power on function is available only in RS-232C connection
with 9600 baud.
• Use WoL function when using IP connection.
• When the TV is powered off via RS232C, please wait
approx. 30 seconds before sending the power on
command.
1 Return from standby mode
R 1 Normal mode
"0" (standby mode) and "2" (input signal waiting mode) are
not available on the display.
INPUT MODE
SELECTION
INPS WR 0~6 0~6
TV = 0
AV = 1
HDMI1 = 2
HDMI2 = 3
HDMI3 = 4
USB = 5
HOME =6
Function Command Direction Parameter Reply Control Response content Remarks
BRIGHT VLMP WR 1~100 1~100
COLOR MODE BMOD WR 0~10 0~10
7 : Standard
9 : Movie
10 : Game
2 : PC
3 : Dynamic
4 : Dynamic(Fixed)
0 : User
SIZE WIDE WR 1~7 1~7
1 : Auto
2 : Normal
3 : Zoom
4 : Dot by Dot
5 : 4:3
6 : 14:9
7 : 16:9
8 : Letterbox
9 : Panorama
In each case, display mode will be changed to "normal" when
video source has changed and unable to adopt current
display mode.
Function Command Direction Parameter Reply Control Response content Remarks
VOLUME VOLM WR 1~100 1~100
MUTE AUDIO MUTE WR 0-1 0-1 0 MUTE_OFF 1 MUTE_ON
MODEL INF1 R
SERIAL NO SRNO R
Usage Time UTIM WR
MAIN firmware version FMVR R
MAC address RMAC R
RESET RSET W
Others menu
en-US 53
Control of the TV
Using a PC

Sharp AQUOS 4P-B65EJ2U Specifications

General

Screen shape	Flat
LED backlight	Yes
Response time	6 ms
Display diagonal	65 \
Display brightness	330 cd/m²
Display technology	LCD
Native aspect ratio	16:9
LED backlighting type	Direct-lit LED
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Display number of colors	1.07 billion colors
Viewing angle, horizontal	176 °
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1920 x 1080 (HD 1080), 3860 x 2160
Display refresh rates supported	60 Hz
Motion interpolation technology	-
RMS rated power	16 W
Number of speakers	2
Headphone outputs	0
HDMI ports quantity	3
Common interface (CI)	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Power consumption (standby)	- W
Power consumption (typical)	180 W
Package type	Box
Package depth	151.89 mm
Package width	1588.01 mm
Package height	938.02 mm
Package weight	23000 g
Operating temperature (T-T)	0 - 40 °C
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Control type	Wireless
Stand type	Legs stand
Stand color	Black
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)

Weight and Dimensions

Depth (with stand)	73.66 mm
Width (with stand)	1446 mm
Height (with stand)	835.66 mm
Weight (without stand)	16400 g
