SW
No.
Bit
No.
ITEM Soft SW setting and function Factory Setting
15 1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
16 1 RING signal frequency check Used to select the allowable frequency range of RING signal.
Used to perform a communication test by using a simple
switchboard in production process.
1
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
17 1
2
3
4
Pulse dial signal make ratio
adjustment
(10PPS)
Used to adjust the make ratio of 10PPS pulse dial signal.
The set range is –8% to +7%.
Offset = –8 × Bit1 + 4 × Bit2 + 2 × Bit3 + 1 × Bit4 %
Factory setting = 0 %
0
0
0
0
5
6
7
8
Reserved 0
0
0
0
18 1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
19 1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
20 1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
1 : To be checked 0 : Not to be checked
AR-F152
9 – 25
To Next Page
