SW
No.
Bit
No.
ITEM Soft SW setting and function Factory Setting
11 1 Header Used to set the header attachment to the transmitting
document.
0
2 Header in data transfer Used to set the header attachment to the transferring
document.
0
3 Training (EQM) threshold value Used to select the threshold value to judge Success/Failure
of training in reception of training.
0
4 Reserved 0
5
6
7
Non ECM error judgement
threshold value
0
1
0
8 Reserved 0
12 1
2
3
4
5
Activity Report Auto Listing time Used to set the start time of Activity Report.
Setup is made in the unit of one hour, and setup of minutes
cannot be made.
Print start time =
Bit1 × 16 + Bit2 × 8 + Bit3 × 4 + Bit4 × 2 + Bit5 hour 00 min
Set range = 0 ∼ 23
Factory Setting = 00:00
0
0
0
0
0
6 Reserved 0
7 Reserved 0
8 Reserved 0
13 1 Auto recall in direct send 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7
8
Effective compression system in
reception
0
0
14 1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
1 : Not attached 0 : Attached
1 : Not attached 0 : Attached
1 : Easy to fall back 0 : Normal
Bit 5, 6, 7 RTP RTN
000 32 64
001 16 32
010 12 24
011 8 16
100 6 12
101 4 8
1 : Enable 0 : Disable
Bit No.
MH,
MR,
MMR
MH, MR
MH,
MMR
MH
70011
80101
AR-F152
9 – 24
