AR-M236/M276/M237/M277 TROUBLE CODE LIST 9 - 1
[9] TROUBLE CODE LIST
1. List
Trouble code
Trouble contents
Trouble
detection
Main
code
Sub
code
A0 01 Security incompatibility error
E1 00 IMC board communication trouble MCU
10 IMC board trouble
11 IMC ASIC error
12 IMC CODEC error
13 IMC board flash ROM error
14 IMC board expaned memory module
(DIMM) error
15 IMC board Page Memory error/SRAM
error
16 IMC board image compression store
memory error
17 IMC board smoothing IC error
80 IMC PWB communication trouble
(protocol)
81 IMC PWB communication trouble (Parity)
82 IMC PWB communication trouble
(Overrun)
84 IMC PWB communication trouble
(Framing)
88 IMC PWB communication trouble (Time-
out)
E7 02 LSU trouble
10 Shading trouble (black correction)
11 Shading trouble (white correction)
12 Shading trouble
F1 00 Finisher communication trouble FIN
01 Finisher jogger shift trouble
06 Finisher shift motor abnormality
08 Finisher staple shift motor trouble
11 Pusher motor trouble
15 Finisher elevator motor trouble
F2 02 Toner supply failure
04 Identification error
Model error
Type error
Destination error
Data abnormality
Misc error
F5 02 Copy lamp lighting abnormality
F6 00 MCU-FAX communication trouble MCU
10 FAX control PWB trouble
80 FAX control PWB communication trouble
(Protocol)
81 FAX control PWB communication trouble
(Parity)
82 FAX control PWB communication trouble
(Over-run)
84 FAX control PWB communication trouble
(Framing)
88 FAX control PWB communication trouble
(Timeout)
99 FAX control PWB destination error
F9 00 MCU-PRT communication trouble MCU
10 Printer PWB trouble
80 Printer PWB communication trouble
(Protocol)
81 Printer PWB communication trouble
(Parity)
82 Printer PWB communication trouble
(Overrun)
84 Printer PWB communication trouble
(Framing)
88 Printer PWB communication trouble
(Timeout)
99 Machine-PCL board language error
H2 00 Main heater lamp thermistor open hard
detection
01 Sub heater lamp thermistor open hard
detection
H3 00 Main heater lamp abnormally high
temperature hard detection trouble
01 Sub heater lamp abnormally high
temperature hard detection trouble
10 Main heater lamp abnormally high
temperature soft detection trouble
11 Sub heater lamp abnormally high
temperature soft detection trouble
H4 00 Main heater lamp abnormally low
temperature detection
01 Sub heater lamp abnormally low
temperature detection
20 Main heater lamp abnormally low
temperature detection
21 Sub heater lamp abnormally low
temperature detection
H5 01 10 continuous POD1, POD2 or PPD2
JAM
L1 00 Scanner feed trouble
L3 00 Scanner return trouble
L4 01 Main motor trouble
11 Shifter motor trouble
L6 10 Polygon motor trouble
L8 10 Power abnormality detection trouble
U1 01 FAX battery error
02 PANEL LOW battery error
U2 04 EEPROM communication error
20 Machine speed code data error
40 CRUM chip communication error
U7 00 RIC communication trouble
U9 00 MCU-OPE communication trouble OPE
80 Operation control PWB communication
trouble (Protocol)
81 Operation control PWB communication
trouble (Parity)
82 Operation control PWB communication
trouble (Overrun)
84 Operation control PWB communication
trouble (Framing)
88 Operation control PWB communication
trouble (Time-out)
99 Operation panel language error
EE EL Developer adjustment trouble (Over-toned
abnormality)
EU Developer adjustment trouble (Under-
toned abnormality)
PF 00 RIC copy inhibit signal received
Trouble code
Trouble contents
Trouble
detection
Main
code
Sub
code
