Preparation for Use
Placing the speaker system
To enjoy the surround effect, we recommend that you place each
speaker as shown to the below.
External FM aerial
Use an external FM aerial if you require better reception.
Consult your dealer.
Note:
When an external FM aerial is used, disconnect the supplied FM
aerial wire.
Note:
Front speakers and active subwoofer are not magnetically shielded
and must not be placed near the TV.
If colour variation occurs:
Turn off the TV (from the power switch).
After 15 - 30 minutes, turn the TV on again.
If the colour variation is still present:
Move the speakers further away from the TV.
If any kind of magnet or an electromagnet is placed too close to
the TV and the system, irregular colours may appear on the TV
screen.
Front
speaker
(left)
Front
speaker
(right)
Front
speaker
(right)
Front
speaker
(left)
TV
Main unit
This illustration is for CD-G22000
Active
subwoofer
Active
subwoofer
External FM aerial
75 ohms
coaxial cable
ANTENNA
FM
75 OHMS
AM
GND
