Sharp CV-P09FR Service Manual

CVP09FR
1 – 1
CVP09FR
ServiceManual

CHAPTER 1. PRODUCT SPECIFICATION
[1] SPECIFICATION
[2] ELECTRICAL PARTS
Cooling Capacity kW 2.12
Moisture Removal liters/h 1.17
Electrical Data
Phase Single
Rated frequency Hz 50
Rated voltage V 220 - 240
Rated current A 4.0
Rated input W 880
Power factor % 96
EER W/W 2.41
Compressor
Type (Hermetically sealed rotary type)
Model, Motor Output 5RS084DAC01 (600W)
REFRIGERANT SYSTEM
Evaporator Louver fin, Grooved tube, 7mm, hair pin
Condenser Louver fin, Grooved tube, 7mm, hair pin
Control O.D. x I.D x Length(mm)
(Capillary Tube)
2.7 x 1.2 x 400
Refrigerant Volume R410A (g)
(Factory Charge)
400
NET DIMENSIONS
Width Height Depth mm 470 x 820 x 383
Net Weight kg 36
GROSS DIMENSIONS
Width Height Depth mm 561 x 910 x 465
Gross Weight kg 41
FAN SYSTEM
Indoor side (Evaporator) Centrifugal fan
Outdoor side (Condenser) Centrifugal fan
Air Flow rate (Indoor side)
m
3
/min
High / Med / Low
6.5/5.1/3.9
OTHERS
Safety devices Compressor : Overload relay
Fan motor (IN/OUT) : Internal thermal fuse / Internal thermal protector
Air filter Polypropylene net
Power cord length cm 160
Power plug type Standard sheet CEE7/VII
Running capacitor 400V - 20µF
Fan capacitor (IN/OUT) 450V - 2µF / 450V - 2µF
Thermistor 10kΩ at 25°C (TH1), 4.431kΩ at 25°C (TH2, TH3)
Fan motor (IN) IBH-884-513 (MLB189)
Fan motor (OUT) PFU040AUEA/SHP (MLB188)
Overload relay MRA99212L-9201 or MRA99326
Drain motor ORM-1524P2 (M-A445)

Sharp CV-P09FR Specifications

General

Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.167 l/h
Cooling capacity in watts (max)	2120 W

Weight and Dimensions

Weight	36000 g
